Ductile Iron 11.25 Degree Double Socket Bend Tyton Joint
Application: Municipal Use, Waterworks Pipelines, Piping Fittings, Water Engineering, Potable Water Use, Irrigation Use, Water Supply Project Use, Water Treatment Plants Use, Pumping Stations, Water Utility Sectors, Water-Supply Pressure Pipeline, Potable Water Pumping Station, Stormwater Lines, Fire Water Pumping Station, Fresh Water Pumping Station, ect.
Phone : +86 13406973786
Email : inquiry@bystainless.com
Wechat : +86 13406973786
Whatsapp : +86 13406973786
Contact Us
Email

Product Description

Dimensions of Ductile Iron 11.25 Degree Double Socket Bend Tyton Joint

  DN  L  Mass (kg)  standard
  80  30  7.1  ISO2531/EN545
  100  30  8.9  ISO2531/EN545
  125  35  11.9  ISO2531/EN545
  150  35  14.8  ISO2531/EN545
  200  40  22  ISO2531/EN545
  250  50  30.5  ISO2531/EN545
  300  55  40.5  ISO2531/EN545
  350  60  52  ISO2531/EN545
  400  65  65  ISO2531/EN545
  500
  75  96  ISO2531/EN545



Specification: DN50-DN2000(2"-80"), available with PN10, PN16, PN25 and PN40 flanges

Ductile Iron Flange Fittings Standard: ISO2531, ISO4179, ISO8179, BS EN 545, BS EN598, BS4772, ISO7005-2, EN1092-2:1997, DIN2501, GBT13295

Flange: PN10, PN16 or PN25 drilling in accordance with ISO 7005-2/EN 1092-2.

Fluid Temperature: 0°C-50°C， excluding frost.

Pipe ends: Spigot, socket or flanges.

Internal coating: Cement mortar lining comply with ISO4179 or bitumen painting (Ave. min.70 micron) or Fusion Bonded Epoxy Coating

External coating: Sprayed metallic zinc coating (min.150g/m²) according to ISO8179 + bitumen painting (min.70 micron) or epoxy powder coating or epoxy painting or according to customer’s requirements.

Types: Dismantling Joint, Universal Flange Adaptor, Universal Coupling, Ductile Iron Loose Flange Joint, DI Pipe Fitting, Saddle for PVC Pipe, Repair Clamp, Qucick Flange Adaptor, Gibault Joint, Restrained Flange Adaptor, Restrained Coupling, Valve, etc.

Material:Ductile iron grade 500-7/ 450-12 in accordance with ISO 1083 for ductile iron fitting body and retainer, EPDM/NBR for ring, steel zinced/dacro for stub.

Test: In accordance with ISO 2531 / EN 545 / EN598 and 100% water pressure test.






FAQ

Q: Why choose us?

A: Our company have been in steel business for more than ten years, we are internationally experienced,professional, and we can provide variety of steel products with high quality to our clients.



Q: How is your Payment Term?

A:One is 30% deposit by TT before production and 70% balance against copy of B/L;



Q: Can we visit your factory?

A:Warmly welcome. Once we have your schedule, we will arrange the professional sales team to accompany your visit.



Q: Can you provide sample?

A: Yes, We can provide the samll samples in stock, but the sample will be charged, and  the charge will be refunded if you place an order.



Q: How about your price?

A: Our prices are very favorable and competitive.Customer from all over the world to purchase our products.



Q: How long is your delivery time?

A: Generally it is 15-30 work days if the goods are not in stock, it is according to quantity.



Q:Could you special design and produce for us?
A: Sure, we have all kinds of professional engineers,Could design and produce special product according to customer requested.Such as: special Size, special control, or OEM, etc.
